SPL Dynamics XTR-165D2N

6,5" subwoofer.

2500wRMS.

500wMAX.

2x 2ohm.



Thiele-Small Parameters

Fs(Hz)

54.1

Vas(l)

2.3

Qts

0.38

Qms

5.7

Qes

0.41

Bl(Tm)

19.2

Mms(gr)

110

Cms(mm/N)

0.08

Rms(kg/s)

7.2

Le(mH)

1.7

Re(Ohm)

4.1

Sd(sq.mm)

14238

Vd(l)

0

X-max(mm)

0

X-mech(mm)

0

General Parameters

Diameter (inch)

6

Max Power(W.)

500

RMS Power(W.)

250

Number of Coils

2

Impedance Z-Nom(Ohm)

2

Reference efficiency η0(%)

0.09

Sensitivity(dB) 1-W

81.3

Sensitivity(dB) 2.8-V

84.2

Mounting Information

Speaker Displacement (l)

0

Total Diameter (mm)

165

Cutout Diameter (mm)

162

Mounting Depth (mm)

108

Magnet Diameter (mm)

0

Optimum Enclosures

Enclosures

Vented
